• The MultiFin GNSS + WiFi 6E + Cellular MIMO Combination Antenna from PCTEL is a high-performance, multi-band antenna designed for mission-critical applications requiring simultaneous GNSS, Wi-Fi 6E, and Cellular MIMO connectivity.
• It is optimized for public safety, fleet management, industrial IoT, and autonomous vehicle applications, where high-speed, reliable, and interference-resistant communication is essential.
• The low-profile, aerodynamic design ensures durability and easy installation, making it ideal for vehicular and outdoor deployments.

• Frequency Bands:
  • 5G/LTE Bands: 617-960 MHz, 1710-2700 MHz, 3300-5000 MHz (MIMO support)
  • Wi-Fi 6E Bands: 2.4 GHz, 5 GHz, and 6 GHz (5925-7125 MHz)
  • GNSS Bands:
    • GPS L1 (1575.42 MHz)
    • GLONASS L1 (1602 MHz)
    • Galileo and BeiDou compatibility
• MIMO Technology:
  • 4×4 MIMO for Cellular
  • 4×4 MIMO for Wi-Fi 6E, improving network speed and stability.
• Gain:
  • 5G/LTE: 3-5 dBi
  • Wi-Fi 6E: 5-7 dBi
  • GNSS: 28 dB active gain with low-noise amplifier (LNA)
• Polarization: Vertical, optimized for strong and stable signal reception.
• VSWR (Voltage Standing Wave Ratio): ≤ 2.0:1, ensuring efficient signal transmission.
• Connector Types:
  • Available in SMA, TNC, or N-Type, depending on the configuration.
• Mounting Method:
  • Permanent screw-mount for secure, long-term vehicle or infrastructure installation.
• Enclosure Material: UV-resistant, impact-resistant plastic, designed for extreme environments.
• Ingress Protection: IP67/IP69, providing waterproof and dustproof protection.
• Operating Temperature: -40°C to +85°C, ensuring reliability in harsh conditions.

• Triple-Band Connectivity in One Unit:
  • Eliminates the need for multiple antennas by combining GNSS, Wi-Fi 6E, and Cellular MIMO.
• Wi-Fi 6E for High-Speed Wireless Communication:
  • Provides faster, lower-latency wireless connectivity, making it ideal for modern smart applications.
• Advanced GNSS with High-Rejection Filtering:
  • Ensures accurate and interference-free GPS tracking, even in challenging RF environments.
• MIMO Technology for Improved Data Throughput:
  • Supports multi-stream communication, increasing speed, reliability, and network capacity.
• Durable & Weatherproof Design:
  • IP67/IP69-rated for rugged outdoor and vehicle use.
  • Aerodynamic, low-profile build reduces wind resistance on vehicles.
• Secure Mounting for Mobile Use:
  • Permanent mount design ensures stability, even on high-speed vehicles.

• Public Safety & First Responders:
  • Provides high-speed communication, reliable GPS tracking, and real-time data transmission for police, fire, and EMS vehicles.
• Fleet Management & Transportation:
  • Ensures seamless connectivity for GPS tracking, telematics, and high-speed data transmission in commercial and municipal fleets.
• Industrial IoT & Smart Cities:
  • Supports automated monitoring, asset tracking, and sensor-based communication for smart infrastructure.
• Autonomous Vehicles & V2X Communication:
  • Enhances vehicle-to-vehicle (V2V) and vehicle-to-infrastructure (V2I) communication, essential for ADAS and autonomous driving.
• Remote & Field Operations:
  • Provides strong, stable connectivity for oil & gas, mining, construction, and remote monitoring applications.
• Military & Defense Applications:
  • Offers secure, interference-resistant, and mission-critical communication in demanding environments.

The MultiFin GNSS + WiFi 6E + Cellular MIMO Combination Antenna from PCTEL is a powerful, all-in-one connectivity solution designed for next-generation wireless communication, high-speed data transmission, and precise GPS tracking in mobile, industrial, and public safety applications. 🚀
