• The Multiband 5G Cellular & 802.11ac Antennas with High Rejection GPS/GLONASS from PCTEL are high-performance antennas designed for mission-critical applications requiring reliable cellular, Wi-Fi, and GNSS connectivity.
• These antennas support 5G, LTE, and Wi-Fi 802.11ac networks while integrating a high-rejection GNSS (GPS/GLONASS) element for precise location tracking and strong resistance against interference.
• Designed for transportation, public safety, industrial IoT, and smart city applications, these antennas ensure robust connectivity in demanding environments.

• Frequency Bands:
  • 5G/LTE Bands: 617-960 MHz, 1710-2700 MHz, 3300-5000 MHz
  • Wi-Fi Bands: 2.4 GHz and 5 GHz (802.11ac support)
  • GNSS Bands:
    • GPS L1: 1575.42 MHz
    • GLONASS L1: 1602 MHz
    • High Rejection Filtering: Provides superior protection against out-of-band interference.
• MIMO Technology: Supports 2×2, 3×3, or 4×4 MIMO for enhanced network speed and reliability.
• Gain:
  • 5G/LTE: 3-5 dBi
  • Wi-Fi: 5-7 dBi
  • GNSS: 28 dB active gain with low-noise amplifier (LNA)
• Polarization: Vertical for optimized signal performance.
• VSWR (Voltage Standing Wave Ratio): ≤ 2.0:1, ensuring efficient signal transmission.
• Connector Type: Available in SMA, TNC, or N-Type, depending on the model.
• Mounting Method:
  • Permanent screw-mount for secure, long-term installation.
  • Optional magnetic base for flexible deployments.
• Enclosure Material: UV-resistant, impact-resistant plastic for durability.
• Ingress Protection: Rated IP67/IP69, ensuring waterproof and dustproof protection.
• Operating Temperature: -40°C to +85°C, making it suitable for extreme environments.

• Comprehensive Multiband Support: Covers 5G, LTE, Wi-Fi, and GNSS bands, eliminating the need for multiple antennas.
• MIMO Technology for Faster Data Speeds: Enhances network efficiency, reducing latency and increasing throughput.
• High-Rejection GNSS for Precise Location Tracking:
  • Filters out unwanted signals and interference, ensuring accurate positioning.
  • Essential for fleet management, public safety, and industrial IoT.
• Durable & Weather-Resistant Design:
  • IP67/IP69-rated, making it ideal for outdoor, rugged environments.
  • UV-resistant enclosure protects against environmental damage.
• High Gain for Stronger Connectivity:
  • Provides improved reception and stable connections in low-signal areas.
  • Low VSWR ensures minimal signal loss.
• Flexible Mounting Options: Available in screw-mount and magnetic-base configurations, making it suitable for fixed or temporary applications.

• Public Safety & Emergency Response:
  • Used in police, fire, and EMS vehicles for real-time tracking and communication.
  • High-rejection GNSS ensures accurate location data even in high-interference areas.
• Fleet Management & Transportation:
  • Provides reliable GPS tracking and telematics for trucks, buses, and commercial fleets.
  • Ensures seamless 5G/LTE connectivity for in-vehicle communication.
• Industrial IoT & Smart Cities:
  • Enables automation, sensor-based monitoring, and M2M communication.
  • Supports autonomous systems and remote asset tracking.
• Connected & Autonomous Vehicles:
  • Enhances V2X (vehicle-to-everything) communication.
  • Supports advanced driver assistance systems (ADAS) with high-accuracy GPS.
• Military & Defense Applications:
  • Provides secure, interference-resistant communication in demanding conditions.
  • Supports mission-critical GNSS tracking and tactical networking.

The Multiband 5G Cellular & 802.11ac Antennas with High Rejection GPS/GLONASS from PCTEL offer a powerful, reliable, and rugged solution for advanced communication and precise location tracking, making them ideal for public safety, industrial, and fleet applications. 🚀
